Message
ID
Message Text Explanation
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL01133-
I
aa...aa path(s) were successfully placed
bb...bb; cc...cc path(s) were successfully
placed dd...dd; ee...ee path(s) were not.
Operation name = ff...ff
Details
The number of paths
processed by an online
operation is shown.
aa...aa: The number of
paths which changed to
the Online status
bb...bb: Online or
Online(S)
cc...cc: The number of
paths which changed to
the Online(S) or
Online(D) status
dd...dd: Online(S),
Online(D) or Online(S)/
Online(D)
ee...ee: The number of
paths which failed to
change to either the
Online, Online(S) or
Online(D) status
ff...ff: online
Action
None.
KAPL01134-
I
The target paths are already Online or
Online(S).
Details
The specified paths are
already in the Online or
Online(S) status as a
result of an online
operation.
Action
Check path status by using
the view operation.. For
details on the view
operation, see
view
(Displays Information) on
page 6-34.
For Online(S) paths:
To change the status of a
path from Online(S) to
Online, re-execute the
HDLM command using the
-hapath parameter.
8-28
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
