Message
ID
Message Text Explanation
KAPL01154-
W
The dynamic I/O path control function is
already set to aa...aa for the system.
Details
aa...aa: "on" or "off"
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
setting for the host,
storage, and LUs. For
details on the view
operation, see
view
(Displays Information) on
page 6-34.
KAPL01155-
W
The dynamic I/O path control function is
already set to aa...aa for storage.
Details
aa...aa: "on" or "off"
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
setting for storage. For
details on the view
operation, see
view
(Displays Information) on
page 6-34.
KAPL01156-
I
The dynamic I/O path control function
was set to aa...aa for storage.
Details
aa...aa: "on" or "off"
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
setting for storage and
LUs. For details on the
view operation, see
view
(Displays Information) on
page 6-34.
KAPL01157-
I
The dynamic I/O path control function
was set to aa...aa for the system.
Details
aa...aa: "on" or "off"
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
setting for the host,
storage, and LUs. For
details on the view
operation, see
view
(Displays Information) on
page 6-34.
KAPL01158-
E
Dynamic I/O path control cannot be
applied to the specified storage.
Action
Messages
8-29
Hitachi Dynamic Link Manager (for AIX) User Guide
