Message
ID
Message Text Explanation
Use the view operation of
the HDLM command
(dlnkmgr) to check the
path ID. For details on the
view operation, see view
(Displays Information) on
page 6-34.
KAPL01159-
I
Paths were added. (number of paths
added = aa...aa, completion time =
bb...bb)
Details
This message indicates
that an add operation
succeeded.
aa...aa: number of paths
added
bb...bb: year (4 digits)/
month/date
hour:minute:second
Action
Use the view operation of
the HDLM command
(dlnkmgr) to verify
information about the
added paths.
KAPL01160-
W
The path configuration was not changed. Details
If an add operation was
executed
This message indicates
that no paths were
added.
If a delete operation was
executed
This message indicates
that no paths were
deleted.
Action
If an add operation was
executed
- Execute an OS
command, and check
whether the addition
of paths is recognized
by the OS.
- Use the view
operation of the HDLM
command (dlnkmgr)
to check whether the
paths have already
been added to HDLM.
If a delete operation was
executed
8-30
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
