Message
ID
Message Text Explanation
- Check whether the
paths to be deleted
are in the Offline(C)
status.
- Use the view
operation of the HDLM
command (dlnkmgr)
to check whether the
paths have already
been deleted from
HDLM.
KAPL01161-
I
This operation will change the path
configuration. Do you want to continue?
[y/n]:
Details
This message confirms
whether to perform a path
configuration change by
using an add operation or
delete operation.
Action
Enter y to change the path
configuration, or enter n to
cancel the operation.
KAPL01162-
I
A path was added. (path ID = aa...aa,
storage = bb...bb, iLU = cc...cc)
Details
This message displays
information about a path
added as the result of an
add operation.
aa...aa: path ID of the
added path
bb...bb: storage (vendor
ID.product ID.serial
number) to which the
added path is connected
cc...cc: LU number to
which the added path is
connected
Action
Use the view operation of
the HDLM command
(dlnkmgr) to verify
information about the
added paths.
KAPL01163-
E
The path configuration change failed.
(details = aa...aa)
Details
This message indicates
that an add operation or
delete operation failed.
aa...aa: code indicating the
content of the error
Action
Messages
8-31
Hitachi Dynamic Link Manager (for AIX) User Guide
