Message
ID
Message Text Explanation
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or, if you have a
maintenance contract for
HDLM, the maintenance
company.
KAPL01164-
I
Paths were deleted. (number of paths
deleted = aa...aa, completion time =
bb...bb)
Details
This message indicates
that a delete operation
succeeded.
aa...aa: number of paths
deleted
bb...bb: year (4 digits)/
month/date
hour:minute:second
Action
Use the view operation of
the HDLM command
(dlnkmgr) to verify that
the paths were deleted.
KAPL01165-
I
A path was deleted. (path ID = aa...aa,
storage = bb...bb, iLU = cc...cc)
Details
This message displays
information about a path
deleted as the result of a
delete operation.
aa...aa: path ID of the
deleted path
bb...bb: storage (vendor
ID.product ID.serial
number) to which the
deleted path was
connected
cc...cc: LU number to
which the deleted path was
connected
Action
Use the view operation of
the HDLM command
(dlnkmgr) to verify that
the paths were deleted.
KAPL01166-
I
If you execute this operation, the
specified number of times that the same
path can be used for individual LUs will
become invalid. Do you want to execute
the operation anyway? Operation name =
set [y/n]:
Details
The specified number of
times that the same path
can be used for individual
LUs will become invalid. To
continue the operation,
enter y. To cancel the
operation, enter n.
