Message
ID
Message Text Explanation
Action
If you want to change the
number of times that the
same path can be used for
the system, enter y. To
cancel the operation, enter
n.
KAPL01167-
I
All paths will be set to Online or
Online(D). Is this OK? [y/n]:
Details
All paths will be set to
Online or Online(D)
because no path is
specified. To continue,
enter y. To cancel the
operation, enter n.
Action
To set all paths to Online
or Online(D), enter y. To
cancel the operation, enter
n. Before you execute the
processing, you must
check the path status by
executing the view
operation of the HDLM
command dlnkmgr.
KAPL01168-
I
All P-VOL paths that are connected to the
LU that has the specified path ID will be
set to Online(D). Is this OK? [y/n]:
Details
All paths for each specified
LU will be set to Online or
Online(D). To continue,
enter y. To cancel the
operation, enter n.
Note: All paths of the LU,
including non-P-VOL paths,
will be set to Online or
Online(D).
Action
To set to Online or
Online(D) all paths that
are connected to the LU
that has the specified path
ID, enter y. To cancel the
process, enter n.
KAPL01169-
I
All Online(S) or Online(D) paths will be
set to Online. Is this OK? [y/n]:
Details
All paths in the Online(S)
or Online(D) status will be
set to Online because no
path is specified. To
continue, enter y. To
cancel the operation, enter
n.
