Message
ID
Message Text Explanation
Action
To execute online
processing, enter y. To
cancel the operation, enter
n. Before you execute the
processing, you must
check the path status by
executing the view
operation of the HDLM
command dlnkmgr.
KAPL01170-
I
All Online(S) or Online(D) paths that are
connected to the LU that has the specified
path ID will be set to Online. Is this OK?
[y/n]:
Details
All paths in the Online(S)
or Online(D) status for
each specified LU will be
set to Online. To continue,
enter y. To cancel the
operation, enter n.
Action
To set to online the all
Online(S) or Online(D)
paths that are connected
to the specified LU with
path ID, enter y. To cancel
the operation, enter n.
KAPL01171-
I
The target paths are already aa...aa or
bb...bb.
Details
The specified paths are
already in the Online,
Online(S), or Online(D)
status as a result of an
online operation.
aa...aa: Online or
Online(S)
bb...bb: Online(D) or
Online(S)/Online(D)
Action
Check path status by using
the view operation. For
Online(S) or Online(D)
paths: To change the
status of a path from
Online(S) or Online(D)
to Online, re-execute the
HDLM command with the -
hapath parameter
specified.
KAPL01172-
I
There are no Online(S)/Online(D) paths
among the target paths.
Details
An online operation was
executed using the -hapath
parameter, but there are
no paths with the
8-34
