Message
ID
Message Text Explanation
Online(S)/Online(D)
status among the specified
paths.
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
status of the path.
KAPL01173-
W
The target CHA port was constructed from
multiple physical CHA ports. Operation
name = aa...aa. Specify a physical CHA
port by using the "-cha -pathid"
parameter.
Details
In an environment where
storage systems are
virtualized, when you
specify a CHA port by
using the -chaid
parameter of the offline or
online operation, the CHA
port might be constructed
from multiple CHA ports of
the physical storage
system. In such a case,
you cannot execute the
offline or online operation
with the -chaid parameter
specified.
aa...aa: offline or Online
Action
Specify a physical CHA
port by using the -cha -
pathid parameter, and
then re-execute the
offline or online
operation.
KAPL01174-
W
If the Physical Storage View is disabled,
the parameter value aa...aa cannot be
specified for the -item parameter.
Details
If the Physical Storage
View is disabled, the
parameter value shown
cannot be specified.
aa...aa: virt
Action
When specifying virtual
storage information as a
display item, enable the
Physical Storage View.
KAPL01175-
W
If the Physical Storage View is enabled,
the parameter value aa...aa cannot be
specified for the -item parameter.
Details
If the Physical Storage
View is enabled, the
parameter value shown
cannot be specified.
