Message ID Message Text Explanation
aa...aa: API trace error
information
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL03999-
E
An unexpected error occurred. Details
Conflicting versions of
HDLM modules are being
used.
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04001 to KAPL05000
Message
ID
Message Text Explanation
KAPL04001-
I
HDLM manager started. Action
None.
KAPL04002-
E
Could not start the HDLM manager. Details
The HDLM manager failed
to start because the
current environment is
unsuitable for the HDLM
manager to run in.
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
8-38
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
