Message
ID
Message Text Explanation
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04003-
E
The startup parameter is invalid. Details
The HDLM manager
internal parameter is
invalid.
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04004-
I
HDLM manager will now terminate. Action
None.
KAPL04008-
E
Cannot open the option definition file
(aa...aa).
Details
HDLM manager could not
start normally because it
was unable to open the
option definition file.
aa...aa: Option definition
file name
Action
Check whether another
program is currently using
this file (for example, the
file is being opened in a
text editor), or whether
the file has been
inadvertently deleted.
KAPL04009-
E
The option definition is invalid. Details
HDLM manager could not
start normally because
some of the definitions in
the option definition file
were invalid.
Action
Messages
8-39
