Message
ID
Message Text Explanation
If the KAPL04033-W
message is output after
this message, execute the
dlnkmgr view -sys -
sfunc command, and then
check the option settings.
For options with setting
values that have returned
to default values, use the
dlnkmgr set operation to
reset the values.
If the KAPL04033-W
message is not output,
restart HDLM manager.
If the same error occurs,
re-install HDLM. For details
on the view operation, see
view (Displays
Information) on page 6-34.
For details on the set
operation, see
set (Sets Up
the Operating
Environment) on page
6-18.
KAPL04010-
E
Could not open the error log file. Details
HDLM manager cannot
start normally (unable to
open the error log
file /var/opt/
DynamicLinkManager/log/
dlmmgr[1-16].log).
Action
Check whether another
program is using the file
(or has opened the file
with Notepad), or whether
the error log file has been
deleted inadvertently.
KAPL04011-
E
Could not output the error log file. Details
The log information could
not be output to the error
log file /var/
DynamicLinkManager/log/
dlmmgr[1-16].log.
Action
Make sure that the disk
has enough unused
capacity.
KAPL04012-
E
Could not create a communication pipe.
RC = aa...aa
Details
8-40
Messages
