Message
ID
Message Text Explanation
HDLM manager could not
start normally because it
was unable to create a
pipe file, which is used in
communication with HDLM
commands.
aa...aa: OS error code
(decimal (base-10)
number)
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04013-
E
Input is impossible via the communication
pipe. RC = aa...aa
Details
Data could not be read
from the pipe file while
communicating with an
HDLM command.
aa...aa: OS error code
(decimal (base-10)
number)
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04014-
E
Output is impossible via the
communication pipe. RC = aa...aa
Details
Data could not be written
to the pipe file while
communicating with an
HDLM command.
aa...aa: OS error code
(decimal (base-10)
number)
Messages
8-41
