Message
ID
Message Text Explanation
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04019-
E
Could not collect the error information.
RC = aa...aa
Details
An attempt to read the log
information from the alert
driver failed.
aa...aa: API return code
(decimal (base-10)
number)
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04021-
I
HDLM manager information - aa...aa Details
This information is
required for resolving
problems.
aa...aa: HDLM manager
trace information
Action
None.
KAPL04022-
W
HDLM manager warning information -
aa...aa
Details
This information is
required for resolving
problems.
aa...aa: HDLM manager
trace warning information
Action
8-42
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
