Message
ID
Message Text Explanation
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04023-
E
HDLM manager error information - aa...aa Details
This information is
required for resolving
problems.
aa...aa: HDLM manager
trace error information
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL04024-
C
A critical error occurred in the HDLM
manager. (aa...aa)
Details
This information is
required for resolving
problems.
aa...aa: HDLM manager
trace error information
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
Messages
8-43
Hitachi Dynamic Link Manager (for AIX) User Guide
