Message
ID
Message Text Explanation
KAPL04025-
C
A memory shortage occurred in the HDLM
manager.
Details
There was not enough
memory to run the HDLM
manager processes.
Action
Increase the amount of
memory available for the
process.
KAPL04026-
I
The temporary license is valid. The
license expires in aa...aa days on
(bb...bb).
Details
aa...aa: Expiration day
bb...bb: The year of grace
(4 numeric characters)/
Month (01-12)/Day
(01-31)
Action
Install a permanent license
by the expiration day.
KAPL04027-
I
The emergency license is valid. The
license expires in aa...aa days on
(bb...bb).
Details
aa...aa: Expiration day
bb...bb: The year of grace
(4 numeric characters)/
Month (01-12)/Day
(01-31)
Action
Install a permanent license
by the expiration day.
KAPL04028-
E
The temporary license expired. Action
Install a permanent
license.
KAPL04029-
E
The emergency license expired. Action
Install a permanent
license.
KAPL04030-
E
The temporary license has already
expired.
Action
Install a permanent
license.
KAPL04031-
E
The emergency license has already
expired.
Action
Install a permanent
license.
KAPL04032-
C
A fatal error occurred in HDLM. The
system environment is invalid
Details
A part of the HDLM
configuration file is
missing.
Action
Re-install HDLM.
