Message
ID
Message Text Explanation
KAPL04033-
W
The option definition file was re-created. Details
When an existing option
definition file cannot be
read, a new option
definition file will be re-
created by using the
default values. If some of
the options can be read,
those values can be used.
As for any remaining
values, the default values
will be used.
Action
For any non-defaults
options, use the dlnkmgr
set operation to set the
options again. For details
on the set operation, see
set (Sets Up the Operating
Environment) on page
6-18.
KAPL04034-
E
An attempt to create the option definition
file has failed.
Details
An attempt to re-create an
option definition file (/usr/
DynamicLinkManager/
config/dlmmgr.xml) using
the default values has
failed.
Action
Remove unnecessary files
and secure unused
capacity on the file system,
Check the write
permissions for the
directory and file.
KAPL04035-
I
The path health check will now start.
Total number of paths = aa...aa
Details
aa...aa: Total number of
paths
Action
None.
KAPL04036-
I
The path health check for the path aa...aa
was executed. Number of error paths =
bb...bb
Details
The path health check has
completed normally.
aa...aa: Number of paths
targeted for path health
checking.
bb...bb: Number of paths
determined to have an
Messages
8-45
Hitachi Dynamic Link Manager (for AIX) User Guide
