Message
ID
Message Text Explanation
error by path health
checking.
Action
None.
KAPL04037-
I
The path health check completed
normally. Path ID = aa...aa
Details
All the paths that path
health checking examined
are fine.
aa...aa: Path ID for the
path examined by path
health checking.
Action
None.
KAPL04042-
I
HDLM SNMP TRAP information - aa...aa Details
All the paths that path
health checking examined
are fine.
aa...aa: Start or stop
Action
None.
KAPL04045-
I
HDLM SNMP TRAP was sent. Trap ID =
aa...aa, IP Address = bb...bb, Port
Number= cc...cc, Community = dd...dd,
Trap Data = ee...ee
Details
SNMP TRAP was sent.
aa...aa: Trap ID
bb...bb: Destination IP
address of the trap
cc...cc: Destination port
number of the trap
dd...dd: Community name
given to the trap
ee...ee: Transmission data
Action
None.
KAPL04046-
E
An attempt to connect to the HDLM alert
driver has failed. RC = aa...aa. The HDLM
manager will now terminate.
Details
An attempt to connect to
the HDLM alert driver
during HDLM manager
startup has failed. The
HDLM manager will now
terminate.
aa...aa: OS error code
(decimal number)
Action
See Installing HDLM on
page 3-18, and then
complete the installation.
If the same error continues
8-46
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
