Message
ID
Message Text Explanation
to occur even after the
procedure is performed,
execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or maintenance company if
there is a maintenance
contract for HDLM. For
details on the DLMgetras
utility, see
DLMgetras
Utility for Collecting HDLM
Error Information on page
7-5.
KAPL04053-
W
The option definition file was recovered
from a work file.
Action
Execute the dlnkmgr view
-sys command to check
whether the settings are
recovered. If the settings
are not recovered, execute
the dlnkmgr set operation
to recover the settings. For
details on the view
operation, see
view
(Displays Information) on
page 6-34. For details on
the set operation, see set
(Sets Up the Operating
Environment) on page
6-18.
KAPL04054-
I
The owner controller will now be revised.
(number of LUs = aa...aa)
Details
aa...aa: number of
targeted LUs
Action
None.
KAPL04055-
I
The owner controller was revised.
(number of changed LUs = aa...aa)
Details
aa...aa: number of
changed LUs
Action
None.
KAPL04056-
W
The owner controller cannot be revised
because no paths are in the Online status.
(LU = aa...aa)
Details
aa...aa: ID (serial number
+ iLUN) of the LU that was
not revised
Action
Recover the paths from the
failure, and then place
them in the Online status,
Messages
8-47
