Message
ID
Message Text Explanation
or exclude the LU from
dynamic I/O path control.
KAPL05001 to KAPL06000
Message ID Message Text Explanation
KAPL05003-I The HDLM driver (filter component) was
successfully attached to Disk (aa...aa),
Partition (bb...bb).
Details
The path corresponding to
Disk (aa...aa: Disk
sequence number) and
Partition (bb...bb: Fixed
at 0) was successfully
registered in the core
logic.
Action
None.
KAPL05008-
E
Could not allocate memory. (aa:bb)
Execute the DLMgetras utility to collect
error information, and then contact your
vendor or maintenance company. Refer
to the HDLM User's Guide for instructions
how to execute the DLMgetras utility.
Details
The OS memory allocation
function was started but
an error was returned from
the memory allocation
function.
aa...aa: Number of
program lines
bb...bb: Memory capture
size
Action
Check whether the HDLM
driver has started
normally. If it has not
started or contains an
error, execute the
DLMgetras utility for
collecting HDLM error
information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL05011-
E
Could not attach the HDLM driver (filter
component) to Disk (aa), Partition (bb).
(cc:dd) Execute the DLMgetras utility to
collect error information, and then
Details
Registration of the path
corresponding to Disk
(aa...aa: physical volume
8-48
