Message ID Message Text Explanation
contact the HDLM vendor
or the maintenance
company if you have a
maintenance contract for
HDLM
KAPL05021-I Processing of IOCTL (aa...aa) completed
normally.
Details
The processing for the
requested IOCTL operation
was successful.
aa...aa: IOCTL code
(hexadecimal number)
Action
None.
KAPL05023-
E
Could not process the IOCTL(aa). (aa:cc)
Check the message of the HDLM
command or the HDLM manager, and
then take the appropriate action. If you
do not know the appropriate action,
execute the DLMgetras utility to collect
error information, and then contact your
vendor or maintenance company. Refer
to the HDLM User's Guide for instructions
how to execute the DLMgetras utility.
Details
Processing corresponding
to the requested IOCTL
(aa...aa: IOCTL code
(hexadecimal number)) is
unsuccessful.
bb...bb: Fixed at 0
cc...cc: Fixed at 0
Action
Check the message of the
HDLM command (dlnkmgr)
or the HDLM manager, and
then take the appropriate
action. If you do not know
the appropriate action,
execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM and report the error
and detail code. For details
on the DLMgetras utility,
see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL05501-
E
The path could not be created. (aa...aa,
bb...bb, cc) Execute the DLMgetras utility
to collect error information, and then
contact your vendor or maintenance
company. Refer to the HDLM User's
Guide for instructions how to execute the
DLMgetras utility.
Details
The driver instance could
not be registered in the
kernel side.
aa...aa: HDLM driver
instance name
bb...bb: Logical device file
name of hdisk
cc...cc: Error code
(decimal number)
8-50
