Message ID Message Text Explanation
Action
Contact your HDLM vendor
or maintenance company if
you have a maintenance
contract for HDLM.
KAPL05508-I Data for maintenance(PathCheck): Error
Code = aa...aa, Status Validity =
bb...bb, Status Code = cc...cc, Sense
Code = dd...dd
Details
This message outputs the
details of a path check
error.
aa...aa: Error code
bb...bb: Status Validity
cc...cc: Status code
dd...dd: Sense code
Action
None.
KAPL05509-I Data for maintenance(Adapter): Error
Code = aa...aa, Buffer Flag = bb...bb,
Adapter Status = cc...cc, Add Adapter
Status = dd...dd
Details
This message outputs the
details of a path failure.
aa...aa: Error code
bb...bb: Buffer flag
cc...cc: Adapter status
dd...dd: Additional adapter
status
Action
None.
KAPL05510-I Data for maintenance(SCSI): Error Code
= aa...aa, Buffer Flag = bb...bb, SCSI
Status = cc...cc, Add SCSI Status =
dd...dd
Details
This message outputs the
details of a path failure.
aa...aa: Error code
bb...bb: Buffer flag
cc...cc: SCSI status
dd...dd: Additional SCSI
status
Action
None.
KAPL05511-I Data for maintenance(Other): Error Code
= aa...aa, Buffer Flag = bb...bb, Status
Validity = cc...cc
Details
This message outputs the
details of a path failure.
aa...aa: Error code
bb...bb: Buffer flag
cc...cc: Status Validity
Action
None.
Messages
8-51
Hitachi Dynamic Link Manager (for AIX) User Guide
