Message ID Message Text Explanation
KAPL05512-I Data for maintenance(SenseData):
Sense Key = aa...aa, Sense Code =
bb...bb
Details
This message outputs the
details of a path failure.
aa...aa: Sense Key
bb...bb: Sense Code
Action
None.
KAPL05819-I Data for maintenance: aa...aa bb...bb
cc...cc dd...dd.
Details
The filter driver outputs
this message for
maintenance.
aa...aa: Device minor
number
bb...bb: Message output
location information
cc...cc: Detailed
information 1
dd...dd: Detailed
information 2
Action
None.
KAPL06001 to KAPL07000
Message ID Message Text Explanation
KAPL06003-I Initialization of the HDLM alert driver
(aa...aa) was successful.
Details
Initialization of the alert
driver (aa...aa: alert driver
management table address
(hexadecimal number))
completed normally.
Action
None.
KAPL06004-
E
Could not allocate memory.
(aa...aa:bb...bb)
Details
An attempt to reserve
memory to save alert
information has failed.
aa...aa: Program line
(hexadecimal number)
bb...bb: Target memory
size (hexadecimal number)
Action
Check whether the HDLM
driver has started
normally. If it has not
8-52
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
