Message ID Message Text Explanation
started or contains an
error, execute the
DLMgetras utility for
collecting HDLM error
information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM and report the error
and detail code. For details
on the DLMgetras utility,
see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL06009-I Invalid IOCTL (aa...aa) was received.
The processing is canceled.
Details
A request having an invalid
IOCTL code (aa...aa:
IOCTL code (hexadecimal
number)) was issued to
the alert driver.
Action
None.
KAPL06010-
E
Could not process the IOCTL (aa...aa).
(bb...bb:cc...cc)
Details
Although the IOCTL
request (aa...aa: code
(hexadecimal number))
from the HDLM manager or
API was accepted, it is not
one of the requests
expected to be processed
by the alert driver.
bb...bb: error code
(hexadecimal number)
cc...cc: 0 (fixed)
Action
Check the message of the
HDLM command (dlnkmgr)
or HDLM manager, and
then take the appropriate
action. If you do not know
the appropriate action,
execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM and report the error
and detail code. For details
on the DLMgetras utility,
see
DLMgetras Utility for
Messages
8-53
