Message
ID
Message Text Explanation
(decimal (base-10)
number)
cc...cc: Detailed
information 2 (decimal
(base-10) number)
dd...dd: Detailed
information 3 (decimal
(base-10) number)
Action
None.
KAPL07824-
I
The owner controller of the LU connected
to the path (aa...aa) was changed to
(bb...bb).
Details
The owner controller of the
LU connected to the path
with the ID shown in the
message was changed.
aa...aa: Path ID of the
changed LU. (same as
PathID of view -path)
(Decimal number)
bb...bb: Owner controller
ID after the change.
(Hexadecimal number)
Action
None.
KAPL07825-
I
The owner core of the LU connected to
the path (aa...aa) was changed to
(bb...bb).
Details
The owner core of the LU
connected to the path with
the ID shown in the
message was changed.
aa...aa: Path ID of the
changed LU. (same as
PathID of view -path)
(Decimal number)
bb...bb: Owner core ID
after the change.
(Hexadecimal number)
Action
None.
KAPL08001 to KAPL09000
Message ID Message Text Explanation
KAPL08019-
E
The path (aa...aa) detected an error
(bb...bb). (cc...cc)
Details
An error occurred in the
path. The error is most
8-56
