Message ID Message Text Explanation
likely due to a
disconnected cable.
aa...aa: Path identifier
(hexadecimal number)
bb...bb: Error code
(hexadecimal number)
¢
When the path error is
detected by a path
health checking or the
online operation
Displays 0x000F0000
(Fixed).
¢
When a path error is
detected through an
I/O error
The OS error code is
displayed.
cc...cc: 0x00000000
(fixed)
Action
Check the path in which
the error was detected.
KAPL08022-
E
A path error occurred. ErrorCode =
aa...aa, PathID = bb...bb, PathName =
cc...cc.dd...dd.ee...ee.ff...ff, DNum =
gg...gg, HDevName = hh...hh
Details
A physical or logical error
occurred in the path.
aa...aa: Error code
(hexadecimal number)
¢
When the path error
was detected by a
path health checking
or the online
operation
Displays 0x000F0000
(Fixed).
¢
When the path error
was detected through
an I/O error
Displays the OS error
code.
bb...bb: Path ID (same as
PathID of view -path)
(decimal number)
cc...cc: HBA adapter
number or Adapter type
(same as PathName of
view -path) (character
string)
dd...dd: Bus number or
Adapter number (character
string)
