Message ID Message Text Explanation
aa...aa: Path ID (same as
PathID of view -path)
(decimal (base-10)
number)
Action
To return a path to the
Online(D) status, resolve
the path failure, and then
execute the "dlnkmgr
online -dfha" command.
KAPL09001 to KAPL10000
Message
ID
Message Text Explanation
KAPL09003-
E
Cannot install in this system. Install
HDLM on a supported OS.
Details
Installation of HDLM failed
because the OS is not
supported. Make sure that
you are using a supported
OS. Also make sure that
the OS is not installed with
the Secure by Default
functionality enabled.
Action
See Host and OS Support
for HDLM on page 3-3 and
install HDLM on a
supported OS.
KAPL09011-
E
Cannot find a license key file "/var/DLM/
dlm.lic_key".
Details
The license key
file/var/DLM/dlm.lic_key
is not in the specified
directory.
Action
Create a license key file,
and re-execute the
installation program.
KAPL09012-
I
All HDLM drivers were removed. Details
All the HDLM drivers were
successfully removed, the
HDLM manager was
successfully stopped, and
HDLM was stopped.
Action
None.
