Message
ID
Message Text Explanation
KAPL09013-
E
Some HDLM drivers could not be
removed.
Details
The dlmrmdev command
was run, but HDLM drivers
could not be removed.
Action
Check the HDLM driver
status and remove the
drivers.
KAPL09019-
E
An attempt to cancel the registration of
the bundle PP name of Hitachi Network
Objectplaza Trace Library 2 failed.
Remove Hitachi Network Objectplaza
Trace Library 2 by referring to HDLM
User's Guide section "Removing Hitachi
Network Objectplaza Trace Library
(HNTRLib2)".
Action
Manually cancel the PP
name registration, and
then remove Hitachi
Network Objectplaza Trace
Library 2. If the attempt to
cancel the registration of
the PP name and to
remove Hitachi Network
Objectplaza Trace Library 2
fails again, contact your
HDLM vendor or the
maintenance company if
there is a maintenance
contact of HDLM.
KAPL09020-
E
An attempt to remove Hitachi Network
Objectplaza Trace Library 2 failed.
Details
An attempt to remove
HNTRLib2 has failed.
Action
Manually remove Hitachi
Network Objectplaza Trace
Library 2. If the attempt to
remove Hitachi Network
Objectplaza Trace Library 2
fails again, contact your
HDLM vendor or the
maintenance company if
there is a maintenance
contact of HDLM.
KAPL09021-
E
An attempt to register the bundle PP
name of Hitachi Network Objectplaza
Trace Library 2 failed.
Details
An attempt to register the
PP name of HNTRLib 2 has
failed.
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contact of
HDLM.
KAPL09022-
E
HDLM cannot be removed. aa...aa is
running.
Details
