Message
ID
Message Text Explanation
HDLM cannot be removed
because the HDLM
manager, HDLM driver is
running.
aa...aa: HDLM manager,
HDLM driver
Action
Execute the dlmrmdev
utility, and then re-execute
the remove program.
KAPL09023-
E
A file or directory related to HDLM could
not be found. Re-install HDLM.
Details
A target file to copy to the
directory of Hitachi
Command Suite products
other than HDLM could not
be found among the files
related to HDLM
Action
Re-install HDLM.
KAPL09024-
E
An attempt to copy a file or directory
related to HDLM has failed. Refer to the
Messages section of the HDLM User's
Guide for instructions to correct this
problem.
Details
An attempt to copy a file
related to HDLM to the
directory of Hitachi
Command Suite products
other than HDLM has
failed.
Action
If this message is output
while installing HDLM, re-
install HDLM.
If this message is output
while installing a Hitachi
Command Suite product
other than HDLM, re-install
that product.
KAPL09025-
W
An attempt to delete a file or directory
has failed.
Details
An attempt to delete a file
related to HDLM from the
directory of Hitachi
Command Suite products
other than HDLM has
failed.
Action
If the following files or
directories are on the host,
remove them manually.
/usr/HDVM/agent/
classes/com/Hitachi/
soft/HiCommand/DVM/
