Message
ID
Message Text Explanation
KAPL09081-
I
The emergency license has been installed.
The license expires on aa...aa.
Details
The emergency license has
been installed.
aa...aa: Year (4 digits)/
month (01-12)/day
(01-31)
Action
Install a permanent license
by the expiration day.
KAPL09082-
W
The temporary license expired. Action
Enter a permanent license
key.
KAPL09083-
W
The emergency license expired. Action
Install a permanent
license.
KAPL09087-
E
The entered license key is invalid.
Renewal of the license key will now stop.
Obtain a valid license key, and then re-
install HDLM.
Details
The renewal of the license
key will be aborted
because an invalid license
key was entered.
Action
Obtain a valid license key,
and then re-install HDLM.
KAPL09088-
E
The entered license key is invalid. The
HDLM installation will now terminate.
Obtain a valid license key, and then re-
install HDLM.
Action
Obtain a valid license key,
and then re-install HDLM.
KAPL09090-
W
This operation will now be continued
without updating the license.
Details
This operation will continue
without updating the
license.
Action
Install a permanent license
at a later time.
KAPL09091-
E
A fatal error occurred in HDLM. The
system environment is invalid. Contact
your HDLM vendor or the maintenance
company if there is a maintenance
contract of HDLM.
Details
A part of the HDLM
configuration file is
missing.
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract of
HDLM.
