Message
ID
Message Text Explanation
KAPL09100-
E
Installation is not possible because
aa...aa is already installed.
Details
Installation is not possible
because the fileset that
was output in the message
is installed.
aa...aa: DLManager.rte or
AutoPath.rte (character
string)
Action
Re-install after removing
the fileset that was output
in the message.
KAPL09112-
E
The license key file is invalid. File name =
aa...aa
Place the correct license key file in the
designated directory, and then re-install
HDLM.
Details
The format of the license
key file is invalid.
aa...aa : /var/tmp/
hdlm_license
Action
Place the correct license
key file in the designated
directory, and then re-
install HDLM.
/var/tmp/hdlm_license
KAPL09113-
E
There is no installable license key in the
license key file. File name = aa...aa
Make sure that the license key file is
correct, and then re-install HDLM.
Details
There is no HDLM-
installable license key in
the license key file.
aa...aa : /var/tmp/
hdlm_license
Action
Make sure that the license
key file is correct, and then
re-install HDLM.
/var/tmp/hdlm_license
KAPL09114-
I
There is no license key file. File name =
aa...aa
Details
There is no license key file
in the designated
directory.
aa...aa : /var/tmp/
hdlm_license
Action
When the message that
prompts you to enter the
license key is displayed,
enter the license key.
Alternatively, cancel the
installation, save the
8-66
