Message
ID
Message Text Explanation
correct license key file in
the designated directory,
and then re-execute the
installation.
/var/tmp/hdlm_license
KAPL09115-
W
An attempt to delete the license key file
has failed. File name = aa...aa
Details
An attempt to delete the
license key file has failed.
aa...aa : /var/tmp/
hdlm_license
Action
If a license key file exists,
delete it.
/var/tmp/hdlm_license
KAPL09116-
W
The command could not be installed.
(command = aa...aa)
Details
The output HDLM
command cannot be used.
aa...aa: Command name
Action
The output command can
be executed by using a
different name. If you
want to use the output
name, use the output
command to overwrite or
re-install.
KAPL09135-
E
One of the following was executed at the
same time as an HDLM command set -lic
operation: another set -lic operation, or
an update of the license for an update
installation.
Action
Check the license by using
the HDLM command's view
-sys -lic operation.
Then, if necessary, update
the license by using the
set -lic operation during
or after installation. If the
same error message is
output, contact your HDLM
vendor or the maintenance
company if there is a
maintenance contract for
HDLM.
Do not perform the
following operation:
Execution of the HDLM
command's set -lic
operation simultaneously
with an update of the
license for an upgrade
installation
