Message
ID
Message Text Explanation
KAPL09142-
E
HDLM aa...aa cannot be performed. Wait
a while, and then perform aa...aa again.
Error Code =bb...bb
Details
HDLM cannot be installed
or removed.
aa...aa: "installation" or
"remove"
bb...bb: Internal code
(decimal (base-10)
number)
Action
Wait a while, and then
reperform the installation
or remove. After the
installation or remove has
finished, use the backup
acquired in advance and
specify the HDLM settings.
KAPL09143-
E
HDLM aa...aa cannot be performed. Error
Code = bb...bb
Details
HDLM cannot be installed
or removed.
aa...aa: "installation" or
"remove"
bb...bb: Internal code
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL09171-
E
An internal error occurred in the
installation of the HDLM. Error Code =
aa...aa bb...bb
Details
A system-based error, not
caused by the user,
occurred during installation
of HDLM processing.
aa...aa:The error number
which specifies the
performed processing
(decimal number)
bb...bb:Return value of the
executed processing
(decimal number)
Action
If the error code is
3,nnnn:
ODM is being used.
Wait a while, and then
try again.
8-68
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
