Message
ID
Message Text Explanation
If any other error code is
output:
Contact your HDLM
vendor or the
maintenance company
if there is a
maintenance contract
for HDLM.
KAPL09172-
E
Installation is not possible because an
hdisk exists.
Action
Delete the hdisk, and then
re-execute the installation
program.
KAPL09179-
I
Data for maintenance: aa...aa bb...bb Details
aa...aa: Message output
location information
(decimal (base-10)
number)
bb...bb: Detailed
information (character
string)
Action
None.
KAPL09183-
I
HDLM version aa...aa is installed. This
version will now be overwritten with
version bb...bb.
Details
aa...aa: Installed version
number of HDLM
bb...bb: Version number of
HDLM you attempted to
install
Action
None.
KAPL09187-
W
No parameter is specified. Details
No installation-information
settings file has been
specified in the
installhdlm utility for
installing HDLM.
Action
Make sure that an actual
installation-information
settings file for the
installhdlm utility is
appropriate, and then try
again.
KAPL09188-
W
Too many parameters are specified. Details
More than two parameters
have been specified for the
installhdlm utility for
installing HDLM.
