Message
ID
Message Text Explanation
Action
Make sure that the
parameters for
installhdlm are
appropriate, and then try
again.
KAPL09190-
W
The installation information settings file is
not specified.
Details
The installation information
settings file is not specified
for the second parameter
in the installhdlm utility
for installing HDLM.
Action
Make sure that the
parameters in the
installhdlm utility are
appropriate, and then try
again.
KAPL09191-
W
The installation information settings file
does not exist.
Details
The installation information
settings file specified for
the second parameter does
not exist.
Action
Make sure that the path
name of the installation-
information settings file is
appropriate, and then try
again.
KAPL09210-
I
aa...aa will now start. Details
aa...aa has just started.
aa...aa: installhdlm,
installp, cfgmgr,
dlmodmset, dlnkmgr, or
dlmrmdev
Action
None.
KAPL09211-
I
aa...aa completed successfully. Details
aa...aa completed
successfully.
aa...aa: installhdlm,
installp, cfgmgr,
dlmodmset, dlnkmgr, or
dlmrmdev
Action
None.
