Message
ID
Message Text Explanation
KAPL09212-
E
aa...aa ended abnormally. Details
aa...aa ended abnormally.
aa...aa: installhdlm,
installp, cfgmgr,
dlmodmset, dlnkmgr, or
dlmrmdev
Action
Check the error message
that was output just before
this message, and then
perform the action
indicated in that error
message.
KAPL09213-
W
An error occurred during aa...aa
processing.
Details
Although the aa...aa
processing has ended, an
error occurred during the
processing.
aa...aa: installhdlm,
installp, cfgmgr,
dlmodmset, dlnkmgr, or
dlmrmdev
Action
Check the error message
that was output just before
this message, and then
perform the action
indicated in that error
message.
KAPL09214-
W
A parameter is invalid. parameter =
aa...aa
Details
A parameter is invalid.
aa...aa: The specified
parameter (character
string)
Action
Specify the -h parameter
for the installhdlm utility,
confirm the parameter that
should be specified, and
then retry the operation.
KAPL09215-
E
The system environment is invalid. Error
Code = aa...aa
Details
The system environment is
not valid as an
environment for executing
the installhdlm utility.
aa...aa: Error number
(decimal number) that
Messages
8-71
