Message
ID
Message Text Explanation
If the error code is 7:
There is not enough
unused capacity for
the file system of
the /var/tmp
or /var/DLM directory.
Make sure there is
enough unused
capacity for these
directories.
If the error code is 8:
The /var directory
does not have enough
unused capacity, or
the user does not have
write permission for it.
Make sure there is
enough unused
capacity and that the
user has write
permission for this
directory, and then try
again.
If the error code is 9:
The status of the
installed HDLM is
BROKEN. Please remove
HDLM.
If the error code is 10:
The cfgmgr command
is not in the correct
location, or you do not
have a required
permission.
Check the state of the
cfgmgr command.
If the error code is 11:
The shutdown
command is not in the
correct location, or
you do not have a
required permission.
Check the state of the
shutdown command.
KAPL09216-
E
An error occurred during I/O of a file that
installhdlm uses. Error Code =
aa...aa,bb...bb
Details
An error occurred during
I/O of a file that
installhdlm uses.
aa...aa: Error number that
indicates the executed
Messages
8-73
