Message
ID
Message Text Explanation
processing (decimal
(base-10) number)
bb...bb: Return value of
the executed processing
(decimal (base-10)
number)
Action
Make sure that sufficient
unused capacity exists for
the /tmp directory. If the
capacity is insufficient,
allocate the required
amount of capacity, and
then retry the operation.
For details about how to
determine the amount of
capacity that is required,
see
Performing an
Unattended Installation of
HDLM on page 3-69.
KAPL09217-
E
An error occurred during reading of the
installation information settings file. Error
Code = aa...aa,bb...bb
Details
An error occurred while
reading the installation
information settings file.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
Action
If the error code
is9001 ,-1:
You do not have read
permissions for the
installation information
settings file. Make
sure that you have
access permissions.
If any other error code is
output:
Contact your HDLM
vendor or the
maintenance company
if there is a
maintenance contract
for HDLM.
KAPL09218-
E
aa...aa cannot be executed. Details
A utility or command that
installhdlm uses was not
8-74
