Message
ID
Message Text Explanation
bb...bb: Return value
(decimal number) of the
executed processing
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL09220-
W
The composition of the installation
information settings file is invalid. Error
Code = aa...aa,bb...bb
Details
In the installation
information settings file,
the length of a single line
exceeds 1,023 characters,
or the first non-
whitespace, non-comment
line that appears is not
[INSTALLATION_SETTINGS]
.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
Action
Specify the revised
installation information
settings file, and then retry
the operation.
KAPL09221-
W
The definition of the installation
information settings file includes an
unusable character. Error Code =
aa...aa,bb...bb, line = cc...cc
Details
A character that cannot be
used in a non-comment
line was used.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
8-76
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
