Message
ID
Message Text Explanation
settings file, and then retry
the operation.
KAPL09227-
W
The definition of the installation
information settings file includes an
invalid key. Error Code = aa...aa,bb...bb,
line = cc...cc
Details
A key that does not exist is
included.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
settings file and then retry
the operation.
KAPL09228-
W
The definition of the installation
information settings file includes an
invalid key value. Error Code =
aa...aa,bb...bb, line = cc...cc
Details
The format of a key value
is invalid.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
settings file and then retry
the operation.
KAPL09229-
W
The definition of the installation
information settings file includes an
invalid section name. Error Code =
aa...aa,bb...bb, line = cc...cc
Details
A section that does not
exist is included.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
Messages
8-77
