Message
ID
Message Text Explanation
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
settings file and then retry
the operation.
KAPL09230-
W
The definition of the installation
information settings file includes a
duplicated section name. Error Code =
aa...aa,bb...bb, line = cc...cc
Details
A duplicated section name
is included.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
settings file and then retry
the operation.
KAPL09231-
W
The definition of the installation
information settings file includes a
duplicated key. Error Code =
aa...aa,bb...bb, line = cc...cc
Details
A duplicated key is
included.
aa...aa: Error number
(decimal number) that
specifies the executed
processing
bb...bb: Return value
(decimal number) of the
executed processing
cc...cc: Line number
(decimal number) of an
installation information
settings file.
Action
Specify the revised
installation information
