Message
ID
Message Text Explanation
Specify the revised
installation information
settings file and then retry
the operation.
KAPL09235-
E
The log file cannot be output to its
destination because the environment is
invalid. Error Code = aa...aa
Details
The log file cannot be
output in this environment,
because certain
environment settings are
invalid.
aa...aa: Error number
(decimal number) that
specifies the executed
processing.
Action
If the error code is 1:
The log file destination
directory does not
exist. Prepare the
directory, and then
retry the operation.
If the error code is 2:
You do not have write
permission for the log
file destination
directory. Modify your
access permissions as
necessary, and then
retry the operation.
If the error code is 3:
You do not have write
permission for the file
system of the log file.
Modify your access
permissions as
necessary, and then
try again.
If the error code is 4:
You do not have write
permission for the
installhdlm.log file.
Modify your access
permissions as
necessary, and then
retry the operation.
KAPL09236-
W
An error occurred during the output of a
log file.
Details
A memory shortage
occurred at the output
destination of the log file.
Action
8-80
