Message
ID
Message Text Explanation
Check the error message
output before this
message, and then
perform the action
indicated in that error
message.
KAPL09237-
I
A user operation ended installhdlm. Details
The process has been
terminated by an operation
such as Ctrl+C.
Action
Check the status of HDLM
by executing lslpp -la
DLManager.mpio.rte.
If HDLM is not installed:
Re-execute
installhdlm.
If the status of HDLM is
COMMITTED:
Perform the following
procedures according
to the installation
status:
• If installing HDLM
by using the
installhdlm
utility has already
finished, setting
up HDLM might
have not
completed.
You need to
manually set up
the values that
are not set up, or
re-execute
installhdlm.
• If HDLM before
the upgrade or re-
installation still
exists, re-execute
installhdlm.
If the status of HDLM is
not COMMITTED:
Perform remove or
cleanup according to
the displayed status. If
an remove or cleanup
attempt fails, contact
either your HDLM
vendor or the
Messages
8-81
Hitachi Dynamic Link Manager (for AIX) User Guide
