Message
ID
Message Text Explanation
maintenance company
(if an HDLM
maintenance contract
exists).
KAPL09238-
W
The specified file is not a normal one. Fail
name = aa...aa
Details
A file other than a normal
one (for example, a
directory file or a special
file.) is specified.
aa...aa: Specified file name
(character string)
Action
Specify the correct file,
and then retry the
operation.
KAPL09239-
I
The system will now restart. Details
The host will restart
because restart was
specified in the installation
information settings file.
Action
none.
KAPL09241-
W
An attempt to install an HDLM component
failed. Error Code = aa...aa
Details
An attempt to install an
HDLM component failed.
aa...aa: Error number that
identifies the executed
processing
Action
If there is no need to
access the Hitachi
Command Suite products
that use HDLM remote
access interface, no action
is required. Note that this
requires no particular
action, because HDLM
operation is not affected
when linkage with Global
Link Manager is not used.
If the error code is 3 or
100:
Wait a while, and then
execute dlminstcomp
utility.
If the error code is 5:
Install a prerequisite
JDK version, and then
