Message
ID
Message Text Explanation
re-execute
dlminstcomp utility.
If the error code is 200:
Execute dlminstcomp
utility.
If any other error code is
output:
Contact your HDLM
vendor or the
maintenance company
if there is a
maintenance contract
for HDLM.
KAPL09242-
E
No usable JDK or JRE exists. Details
No prerequisite JDK
version is installed in the
system.
Action
Install a prerequisite JDK
version, and then re-
execute dlminstcomp
utility.
KAPL09243-
I
dlminstcomp completed successfully. Details
dlminstcomp utility
completed successfully.
Action
None.
KAPL09246-
E
An attempt to install an HDLM component
failed because an HDLM component was
operating. Error Code = aa...aa
Details
An attempt to install an
HDLM component failed
because an HDLM
component was operating.
aa...aa: Error number that
identifies the executed
processing
Action
Wait a while, and then re-
execute dlminstcomp
utility.
KAPL09247-
E
An attempt to install an HDLM component
failed. Error Code = aa...aa
Details
An attempt to install an
HDLM component failed.
aa...aa: Error number that
identifies the executed
processing
Action
Messages
