Message
ID
Message Text Explanation
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL09248-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter is
specified.
aa...aa: The specified
parameter (character
string)
Action
With the -h parameter
specified, execute the
dlminstcomp utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL09292-
W
Execution of the dlmpremkcd utility
during installation failed.
Details
Execution of the
dlmpremkcd utility during
installation failed.
Action
Take action according to
the dlmpremkcd utility
message output to the
HDLM utility log during
HDLM installation. If no
dlmpremkcd utility
messages were output to
the HDLM utility log,
execute the dlmpremkcd
utility with the -c
parameter. If you are not
planning to back up the OS
backup of the HDLM
installation environment to
a CD or DVD, no action is
required because this error
does not affect HDLM
operation.
KAPL09293-
W
An attempt to add an HDLM entry to the
Error Record Template Repository failed.
Details
An attempt to add an
HDLM entry to the Error
Record Template
Repository failed.
Action
If HDLM messages are not
output to the OS error log,
no action is required
because this message does
8-84
