Message
ID
Message Text Explanation
not affect HDLM
operations.
If HDLM messages are
output to the OS error log,
execute the following
command:
/usr/bin/errupdate -q -
f /usr/
DynamicLinkManager/
common/.dlmfdrv_err_tem
plate
If the message is output
after command execution
is complete, resolve the
problem according to the
message, and then re-
execute the errupdate
command.
KAPL09504-
E
The language environments of HDLM and
the Service Pack are different.
Details
The Japanese Service Pack
was applied to the English
edition of HDLM, or vice
versa.
Action
Acquire the Service Pack
that has the same
language as the installed
HDLM, and then try again.
KAPL09601-
E
Cannot install in this system. Install
HDLM on a supported OS.
Details
HDLM cannot be installed
on this system.
Action
Execute the installation in
a supported OS.
KAPL09602-
E
The installation will now stop because a
file or directory is missing. Confirm that
the file or directory (aa...aa) exists.
Details
aa...aa: Name of the
missing file or directory
Action
If an installation is
performed from the DVD-
ROM, confirm that the
DVD-ROM is not damaged.
If an installation is
performed by using files
copied from the DVD-ROM,
re-copy all of the DVD-
ROM files.
KAPL09603-
E
The installation will now stop because a
command or utility cannot be executed.
Details
