Message
ID
Message Text Explanation
Confirm that the command or utility
(aa...aa) exists, and that you have the
proper permission.
aa...aa: Name of the
command or utility that
cannot be executed.
Action
When the output
information is an HDLM
utility:
¢
If an installation is
performed from the
DVD-ROM, confirm
that the DVD-ROM is
not damaged.
¢
If an installation is
performed by using
files copied from the
DVD-ROM, re-copy all
of the DVD-ROM files.
After that, confirm the
permission of the
HDLM utility that
caused the error.
When the output
information is an OS
command:
¢
Confirm that the OS
command exists, and
that you have the
proper permission.
KAPL09604-
E
A system error occurred. The installation
will now stop.
(command = aa...aa, error code =
bb...bb)
Details
aa...aa: Command that
failed
bb...bb: Return value
Action
Acquire the log /var/tmp/
hdlm_installux_sh.log,
and then contact your
HDLM vendor or, if you
have a maintenance
contract, contact the
maintenance company.
KAPL10001 to KAPL11000
Message
ID
Message Text Explanation
KAPL10001-
W
No parameter has been specified. Details
No directory to which the
collected information will
