Message
ID
Message Text Explanation
be output has been
specified.
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then
retry. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10002-
W
Too many parameters have been
specified.
Details
Four or more parameters
have been specified.
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then
retry. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10003-
W
The first parameter has not been set to a
directory. Value = aa...aa
Details
The first parameter must
be set to a directory to
which collected information
is output.
aa...aa: First parameter
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then
retry. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10004-
W
The parameter contains an incorrect
value. Value = aa...aa
Details
The first parameter must
be a directory. The second
parameter must be -f.
aa...aa: Invalid parameter
Action
Check the parameters of
the DLMgetras utility for
