Message
ID
Message Text Explanation
collecting HDLM error
information, and then
retry. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10005-
W
The number of parameters is insufficient. Details
The -f parameter exists
but the file for defining the
information to be collected
does not exist.
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then
retry. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10006-
W
The file for defining the information to be
collected does not exist, or cannot be
read. Value = aa...aa
Details
The file for defining the
information to be collected
does not exist, or the
specified file exists but the
permission to read the file
is missing.
aa...aa: Name of the file
for defining the information
to be collected
Action
Check whether the
specified file for defining
the information to be
collected exists, and check
whether you have access
permission for the
specified file.
KAPL10007-
W
A directory has been specified in the third
parameter. Value = aa...aa
Details
The -f parameter is
specified to a directory.
aa...aa: Third parameter
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then
retry. For details on the
8-88
