Message
ID
Message Text Explanation
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10008-
W
You lack write permission for the specified
directory. Value = aa...aa
Details
You do not have write
permission for the
specified directory, or the
creation of a subdirectory
of the specified directory
failed.
aa...aa: first parameter
Action
Check the following.
a. Check whether you
have access
permission for the
specified directory.
b. Check whether the
specified directory
name is correct.
c. Check that the disk
has sufficient unused
capacity.
KAPL10009-
W
The specified directory already exists. Do
you want to overwrite it? [y/n]:
Details
The specified directory
already exists. Enter y to
overwrite it, or n to cancel.
Action
The specified directory
already exists. Enter y to
overwrite the existing file.
Enter n or press any other
key to terminate the
DLMgetras utility for
collecting HDLM error
information without
executing it. For details on
the DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10010-
W
A root directory has been specified. Line
= aa...aa
Details
The root "/" has been
specified as a directory to
be collected in the file for
defining the information to
be collected.
aa...aa: Line number of
the file for defining
